Design and function
Interfaces
12-pole connection assignments for mechanised welding interface (X2):
Pin Signalshape
A
B
C/L Input
D
E
F
G
H
J
K
M

5.14.8 Sensor Voltage

Outside the welding process, there is a voltage of approx. 12 V on the welding torch electrode. If the
electrode comes into contact with the workpiece or the molten pool, the short-circuit produced means that
when using the relevant interface (BUSINT X11/RINT X12), the resultant signal can be used for various
functions (e.g. workpiece search).
46
Circuit diagram signal
name
NC
NC
Not-Aus
NC
Gasdüsensensor 1
NC
NC
NC
NC
NC
NC
Function
Emergency stop for higher level shut-down of the
power source.
To use this function, jumper 1 must be unplugged on
PCB M320/1 in the welding machine.
Contact open = welding current switched off
