NET-4/5 IP, 5-pin
3.
Description of the Device
The Showtec NET-4/5 IP is a device that converts Art-Net or sACN signals to DMX and vice versa. The
housing and connectors have an IP65 rating, which also makes this device suitable for outdoor use.
Front View
Back View
Side View
Product code: 50818
Control panel
Power Pro True connector OUT 100–
230 V 50/60 Hz
Power Pro True connector IN 100–
230 V 50/60 Hz
Fuse T1 A, 250 V
Protective vent
Ethernet LED indicator
Power LED indicator
Fig. 02
5-pin DMX signal connector
5-pin DMX signal connector
5-pin DMX signal connector
5-pin DMX signal connector
Ethernet connector IN
Ethernet connector THRU
Fig. 03
4 x strap slot
Mounting bracket
Safety eye
4 x Mounting bracket thumbscrew
Fig. 04
9
