Enclosure Dimensions - Altronix Maximal3V Installation Manual

1.25"
(31.75mm)
8.5"
(215.9mm)
7.5"
(190.5mm)
26"
(660.4mm)
LEFT
10"
(254mm)
Altronix is not responsible for any typographical errors .
140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056
website: www .altronix .com | e-mail: info@altronix .com | Lifetime Warranty | Made in U .S .A .
IIMaximal3V/5V/7V Series
- 16 -
Enclosure Dimensions (H x W x D approximate):
26" x 19" x 6 .25" (660 .4mm x 482 .6mm x 158 .8mm)
2"
4"
(50.8mm)
(101.6mm)
0.85"
(21.59mm)
1.5"
(38.1mm)
26"
(660.4mm)
1"
(25.4mm)
0.85"
(21.59mm)
19"
(482.6mm)
7"
(177.8mm)
TOP
19"
(482.6mm)
8.9"
(226.06mm) (213.36mm)
8.9"
(226.06mm) (213.36mm)
BOTTOM
19"
(482.6mm)
G26R
Maximal3V / Maximal5V / Maximal7V Access Power Controllers (Fused)
2"
4"
(50.8mm)
(101.6mm)
6.25"
(158.75mm)
0.85"
8.4"
(21.59mm)
1.5"
(38.1mm)
5"
(127mm)
7.5"
(190.5mm)
1"
(25.4mm)
8.4" 0.85"
(21.59mm)
6.25"
(158.75mm)
4" 2"
(101.6mm)
(50.8mm)
1.25"
(31.75mm)
1.5"
(38.1mm)
7"
(177.8mm)
8.5"
(215.9mm)
26"
(660.4mm)
RIGHT
7"
(177.8mm)
2"
(50.8mm)
1.25"
(31.75mm)
MEMBER
