Enclosure Dimensions - Altronix Maximal3F Installation Manual

1.25"
(31.75mm)
8.5"
(215.9mm)
7.5"
(190.5mm)
26"
(660.4mm)
LEFT
10"
(254mm)
Altronix is not responsible for any typographical errors.
140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056
website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty | Made in U.S.A.
IIMaximal3F/5F/7F Series
Maximal3F/Maximal5F/Maximal7F Access Power Controllers (Fused)
Enclosure Dimensions (H x W x D approximate):
26" x 19" x 6.25" (660.4mm x 482.6mm x 158.8mm)
2"
4"
(50.8mm)
(101.6mm)
0.85"
(21.59mm)
1.5"
(38.1mm)
26"
(660.4mm)
1"
(25.4mm)
0.85"
(21.59mm)
19"
(482.6mm)
7"
(177.8mm)
TOP
19"
(482.6mm)
8.9"
(226.06mm) (213.36mm)
8.9"
(226.06mm) (213.36mm)
BOTTOM
19"
(482.6mm)
E24S
2"
4"
(50.8mm)
(101.6mm)
6.25"
(158.75mm)
0.85"
8.4"
(21.59mm)
1.5"
(38.1mm)
5"
(127mm)
7.5"
(190.5mm)
1"
(25.4mm)
8.4" 0.85"
(21.59mm)
6.25"
(158.75mm)
4" 2"
(101.6mm)
(50.8mm)
1.25"
(31.75mm)
1.5"
(38.1mm)
7"
(177.8mm)
8.5"
(215.9mm)
26"
(660.4mm)
RIGHT
7"
(177.8mm)
2"
(50.8mm)
1.25"
(31.75mm)
MEMBER
