Fig. 4 - Maximal7V
Input
220VAC
50/60Hz
Maximal3V / Maximal5V / Maximal7V Access Power Controllers (Fused)
Ground Lug
Power Supply Board
BAT FAIL
L
G
N
NC C NO
Line
Neutral
Optional
12VDC Battery**
**24VDC operation: Connect two (2) 12VDC batteries in series
15
AC
DC
AC FAIL
NC C NO
AC DELAY
Optional
12VDC Battery**
Fig. 4a
Tamper Switch
Honeywell
Model 112
Tamper Switch
or equivalent
(Not Included)
to Access Control Panel
or U.L. Listed
Reporting Device
Enclosure
Edge of
Enclosure
- 9 -
