Hydac FluidAqua Mobil FAM 5 Operating And Maintenance Instructions Manual page 82

The web server supports the following site languages:
• German, English, Italian, French, Spanish
Other languages may not be properly displayed on the web server.
If the power unit is integrated in a network, then the integrated web server
can be accessed via the following IP address.
IP address
192.168.0.30
For changing the IP address, see chapter "Modifying the network settings" on
page 85.
1. If necessary, select the desired language from the drop-down menu.
2. Enter the user name "Web User" and the password
"FAM5WEBSERVER".
3. If you do not wish to enter the user name and password at next login,
click the box "①". Make sure the browser is not set to private or
incognito mode, since it will not save any browser history or
passwords.
4. To log on to the web server, click on "②".
FAM 5
BEWA FAM5 4166129a en-us 2019-03-04.docx
The following IP addresses are used for internal
communication of the unit:
PLC
Control panel
Both IP addresses need to be available in the network or
must be approved.
With remote access, the registration process can
take several seconds.
In case the registration fails, please press the
update key or button in your browser in order to try
en-US
Connect network connection (Ethernet)
Subnet mask
255.255.0.0
-> 192.168.0.30
-> 192.168.0.31.
Page 82 / 148
2019-03-04
