Vacuum pump maintenance

Another vacuum pump is installed depending on type. The maintenance
activities and cycles vary. The following includes the maintenance activities
for the vacuum pump. Check which vacuum pump has been installed on your
unit on the type label of the unit.
Typ
FAM-5-x-x-x-xx-R-x-x-x-x
FAM-5-x-x-x-xx-RD-x-x-x-x

Replacing the active carbon filter cartridge (optional / accessory)

If the vacuum pump has an active carbon filter cartridge at the air outlet, then
it should be replaced after 2 to 6 months, depending on the operating
conditions.
The active carbon filter cartridge absorbs oil vapors and odors from the
exhaust air. Replace the active carbon filter cartridge sooner if exhaust air
quality has noticeably worsened.
To replace the active carbon filter cartridge, proceed as follows:
1. Manually turn the active carbon filter cartridge counterclockwise from the
connecting pieces.
2. Manually turn the new active carbon filter cartridge clockwise on the
connecting pieces.
FAM 5
BEWA FAM5 4166129a en-us 2019-03-04.docx
Tool
Rotary vane vacuum pump with
vacuum pump oil
Dry-running rotary vane vacuum
pump
en-US
Maintenance
For details,
see page
111
118
