Original instructions
Chapter 7: Modifying Your Protector XStream
Side Panel
(Ceiling Enclosure)
Rear Stiffener
Side Panel
(Ceiling Enclosure)
Hood Side Panel
Front Panel
Hood Front Panel
(Ceiling Enclosure)
Figure 7-2
Installing Rear Panels Behind the Fume
Hood
Your Protector XStream Fume Hood can be modified to add a rear panel behind
the fume hood when the fume hood is placed on an island. Contact Labconco
Customer Service for ordering information.
Product Service 1-800-522-7658
36
