Chapter 7: Modifying the Protector Radioisotope
Side Panel
(Ceiling Enclosure)
Rear Stiffener
Side Panel
(Ceiling Enclosure)
Hood Side Panel
Front Panel
Hood Front Panel
(Ceiling Enclosure)
Figure 7-1
Installing Rear Panels Behind the Fume
Hood
Your Protector Fume Hood can be modified to add a rear panel behind the fume
hood when the fume hood is placed on an island (not available on Pass-Through
Fume Hood). Contact Labconco Customer Service for ordering information.
Installing Guardian™ Digital Airflow
Monitor or Guardian™ Airflow Monitor
The Guardian Airflow Monitors continuously monitor face velocity through the
fume hood opening. The fume hood right corner post is factory prepared to mount
either monitor. Contact Labconco Customer Service to order.
Product Service 1-800-522-7658
