Labconco Protector XStream 11041 Series User Manual page 47

Original instructions
Item Quantity
7A 1 9947100, 01, 02
7B 1
7C 1 9947103, 04, 05
7D 1
7E 1
8A 1
8B 1
9A 1
9B 1
9C 1
10A 1
10B 1
11A 1
12A 1
12B 4
13A 1
13B 1
13C 1
13D 1
13E 1
13F 1
13G 1
13H 1
14A 2
14B 2
15A 2
15B 2
15C 1
16 2
17 4
18 2
19 1
20 1 9409601, 02, 03, 05
21 1
22 1
Product Service 1-800-522-7658
Appendix A: Protector XStream Components
Part No. Description
115V Duplex Receptacle (GRAY) Right, Left 4' - 6', Left 8' w/ wires
9818200 Cover Plate 115V Duplex
115V GFCI Duplex Receptacle (GRAY) Right, 4' - 6', Left 8' w/ wires
9818100 Cover Plate, 115V GFCI
9818300 Cover Plate, Blank
LED, Direct Wired T8 x 3' – newest models use on 4' & 8' Hoods – 12 watts each
1297503
LED, Direct Wired T8 x 4' – newest models use on 5' & 6' Hoods – 22 watts each
1297504
LED Light Fixture, 36" – use on 4' Hoods
9945300
LED Light Fixture, 48" – use on 5', 6' Hoods
9945301
LED Light Fixture, 36" Combo – use in 8' Hoods
9945302
1302301 Switch, Rocker
1327500 Switch, Plug (Fills cutout when switch is not used)
9818400 Access Cover
Side Panel, 30" internal deep hoods – NOT SHOWN
9409801
1885308 Screw, Machine #10-24 x .50 Phillips
9436501 Eco-Foil 4'
9436502 Eco-Foil 5'
9436503 Eco-Foil 6'
9436505 Eco-Foil 8'
9436521 PVC Eco-Foil, 4'
9436522 PVC Eco-Foil, 5'
9436523 PVC Eco-Foil, 6'
9436525 PVC Eco-Foil, 8'
1850000 Pulley, Front, 2" Dia. Nylon
9709300 Plastic Pulley (Rear 2")
Cable, Sash 130" – NOT SHOWN
4949902
9414011 Cable Replacement Kit 30"
9545800 Weight Support Bracket Kit
9713300 Bumper, Rubber (lower sash bumper)
Clamp, Cable Replacement (use two each side) – NOT SHOWN
1920100
Threaded Connector (to attach weight to cable) – NOT SHOWN
9935800
9946300 or 01 Wiring Harness, Main
Front Panel, 4', 5', 6', 8'
9410300 Sash Stop Kit (XStream)
Hinged Screw Cap Cover – NOT SHOWN
1598500
43
