Original instructions
Chapter 7: Modifying Your Protector Premier
Side Panel
(Ceiling Enclosure)
Rear Stiffener
Side Panel
(Ceiling Enclosure)
Hood Side Panel
Front Panel
Hood Front Panel
(Ceiling Enclosure)
Figure 7-2
Installing Rear Panels Behind the Fume
Hood
Your Protector Fume Hood can be modified to add a rear panel behind the fume
hood when the fume hood is placed on an island (not available on Pass-Through
Fume Hood). Contact Labconco Customer Service for ordering information.
34 Product Service 1-800-522-7658
