Labconco Protector XStream 11041 Series User Manual page 39

Original instructions
Configure Your Adjustable Height Ceiling Enclosure Kit Catalog Number
Use this key to configure the seven digit catalog number to order your 3-Sided Adjustable Height
Ceiling Enclosure Kit. For example, 9414511 is a 3-Sided Ceiling Enclosure Kit for a 5' Protector
XStream Hood with a height range of 14-19".
9
Product Service 1-800-522-7658
Chapter 7: Modifying Your Protector XStream
4 1
STEP 1. nominal
Select the
width of your fume hood. This
number is the fifth digit of your
catalog number.
3 = 3' (XL Benchtop only)
= 4'
4
5 = 5'
= 6'
6
7 = 7' (XL Benchtop only)
= 8'
8
4 ___
STEP 2.
Select the
based on the model chosen.
Choose 0 for Premier and 1
for XStream. Choose 1 for
PVC. Choose 0, 1 or 2 for
the correct depth of the XL
Benchtop model. Choose 0
or 1 for the correct depth of
Stainless Steel. This is the
sixth digit of your catalog
number.
No. Ext. Depth
0 31.7"
1 37.7"
2 43.7"
___ ___
depth STEP 3.
Choose the correct
height range
the number. This height
range should match the
height between the top of the
hood and the building
ceiling. This is the seventh
digit of your catalog number.
No.
0
1
2
Model
Premier,
XL Benchtop,
Stainless Steel
XStream,
XL Benchtop,
XL Floor-Mounted,
Stainless Steel,
PVC
XL Benchtop,
XL Floor-Mounted
35
that matches
Height Range
11-14"
14-18.6"
18.6-24.4"
