Load and Motor

100 Configuration
(CONFIGURATION)
Value:
Speed control, open loop
(SPEED OPEN LOOP)
Process control, closed loop
(PROCESS CLOSED LOOP)
Function:
This parameter is used to select the configuration
to which the frequency converter is to be adapted.
This makes adaptation to a given application
simple, since the parameters not used in a given
configuration are hidden (not active).
Description of choice:
If Speed control, open loop [0] is selected, normal
speed control is obtained (without feedback
signal) with automatic load and slip compensation
to ensure a constant speed at varying loads.
Compensations are active, but may be disabled in
parameter 134 Load compensation and parameter
136 Slip compensation as required.
If Process control, closed loop [3] is selected, the
internal process regulator is activated to enable precise
control of a process in relation to a given process
signal. The process signal can be set to the relevant
process unit or as a percentage. A feedback signal
must be added from the process and the process
regulator must be set in parameter group 400 Special
functions. Process closed loop is not active if a
DeviceNet card is mounted and Instance 20/70 or
21/71 is chosen in parameter 904 Instance types.
101 Torque characteristic
(TORQUE CHARACT)
Value:
Constant torque
(CONSTANT TORQUE)
Variable torque high
(TORQUE: HIGH)
Variable torque high with CT start
( VT HIGH CT START)
Special motor mode
(SPECIAL MOTOR MODE)
CT = Constant torque
= factory setting. () = display text [] = value for use in communication via serial communication port
18
AKD 2800
Function:
This parameter enables a choice of principle for
adaptation of the U/f ratio of the frequency converter
to the torque characteristic of the load.
Description of choice:
If Constant torque [1] is selected, a load-dependent U/f
[0]
characteristic is obtained, in which output voltage and
output frequency are increased at increasing loads in
[1]
order to maintain constant magnetization of the motor.
Select Variable torque high [2], if the load is
square (centrifugal pumps, fans).
High with CT start [3], are selected if you need a
greater breakaway torque than can be achieved
with the three first characteristics.
NB!:
Load and slip compensation are not active
if variable torque or special motor mode
have been selected.
Select Special motor mode [4], if a special U/f setting
is needed that is to be adapted to the present
motor. The break points are set in parameters
423-428 Voltage/frequency .
Select Constant Torque [1] for use with compressors.
Select Variable torque high [2] for use with condenser
fans or pumps. Use Special motor mode [4] if
several fans are connected in parallel.
NB!:
Please note that if a value set in the nameplate
parameters 102-106 is changed, there will
be an automatic change of parameter 108
Stator resistance and 109 Stator reactance.
102 Motor power P
(MOTOR POWER)
Value:
0.25 - 22 kW
[1]
Function:
Here you must set a power value [kW] P
[2]
corresponding to the motor's rated power. The
factory sets a rated power value [kW] P
[3]
depends on the type of unit.
Description of choice:
[4]
Set a value that matches the nameplate data on the
motor. Settings between one size below and one
size over the factory setting are possible.
M,N
Depends on unit
,
M,N
, that
M,N
