AKD 2800
Thermal load INV [%], parameter 527:
Gives the calculated/estimated thermal load on the
frequency converter. 100% is the cut-out limit.
Digital input, parameter 528:
Gives the signal status from the 5 digital inputs (18, 19,
27, 29 and 33). Input 18 corresponds to the bit on the
extreme left. '0' = no signal, '1' = connected signal.
Terminal 53 analogue input [V], parameter 529:
Gives the voltage value for the signal on terminal 53.
Terminal 60 analogue input [mA], parameter 531:
Gives the present value for the signal on terminal 60.
External reference, parameter 533:
Gives the sum of external references as a percentage
(sum of analogue/pulse/serial communication)
in the range from Minimum reference, Ref to
MIN
Maximum reference, Ref .
MAX
Status word, parameter 534:
Gives the present status word for the frequency
converter in Hex. See Serial communication
for the AKD 2800.
Inverter temperature, parameter 537:
Gives the present inverter temperature on the
frequency converter. The cut-out limit is 90-100
°C, with cut back in at 70 ± 5 °C.
Alarm word, parameter 538:
Gives in Hex code which alarm is on the frequency
converter. See Warning word, extended status
word and alarm word.
Control word, parameter 539:
Gives the present control word on the frequency
converter in Hex. See Serial communication
for the AKD 2800.
Warning word, parameter 540:
States whether there is a warning on the frequency
converter in Hex. See Warning word, extended
status word and alarm word.
Extended status word, parameter 541:
States whether there is a warning on the frequency
converter in Hex code. See Warning word, extended
status word and alarm word.
= factory setting. () = display text [] = value for use in communication via serial communication port
