Description of choice:
Set the value to be shown on the display when the
maximum feedback has been obtained on the selected
feedback input (parameter 308/314 Analogue inputs).
416 Process units
(REF/FEEDB. UNIT)
Value:
No unit ( NO UNIT)
% (%)
ppm (PPM)
rpm (RPM)
bar (BAR)
Cycles/min (CYCLE/MI)
Pulses/s (PULSE/S)
Units/s (UNITS/S)
Units/min. (UNITS/MI)
Units/h (UNITS/H)
°C (°C)
Pa (PA)
l/s (L/S)
3 3
m /s (M /S)
l/min. (L/M)
3 3
m /min. (M /MIN )
l/h (L/H)
3 3
m /h (M /H)
Kg/s (KG/S)
Kg/min. (KG/MIN)
Kg/hour (KG/H)
Tons/min. (T/MIN)
Tons/hour (T/H)
Metres (M)
Nm (NM)
m/s (M/S)
m/min. (M/MIN)
°F (°F)
In wg (IN WG)
gal/s (GAL/S)
3 3
Ft /s (FT /S)
Gal/min. (GAL/MIN)
3 3
Ft /min. (FT /MIN )
Gal/h (GAL/H)
3 3
Ft /h (FT /H)
Lb/s (LB/S)
Lb/min. (LB/MIN)
Lb/hour (LB/H)
Lb ft (LB FT)
Ft/s (FT/S)
Ft/min. (FT/MIN)
= factory setting. () = display text [] = value for use in communication via serial communication port
MG.28.H2.02 -
AKD 2800
Function:
Select among different units to be shown on the display.
The unit is read out if an LCP control unit can be
connected, and if Reference [unit] [2] or Feedback [unit]
[3] has been selected in one of parameters 009-012
Display read-out, and in Display mode. The unit is used
in Closed loop also as a unit for Minimum/Maximum
reference and Minimum/Maximum feedback.
Description of choice:
[0]
Select the required unit for the reference/feed-
[1] back signal.
[2]
[3]
[4]
423 U1 voltage
[5]
(U1 VOLTAGE)
[6]
Value:
[7]
0.0 - 999.0 V
[8]
[9]
Function:
[10]
Parameters 423-428 are used when in parameter
[11]
101 Torque characteristic a selection has been made
[12]
of Special motor characteristic [8]. It is possible to
[13]
determine a U/f characteristic on the basis of four
[14]
definable voltages and three frequencies. The voltage
[15]
at 0 Hz is set in parameter 133 Start voltage.
[16]
[17]
[18]
[19]
[20]
[21]
[22]
[23]
[24]
[25]
[26]
Description of choice:
[27]
Set the output voltage (U1) that is to match the first
[28]
output frequency (F1), parameter 424 F1 frequency.
[29]
[30]
[31]
424 F1 frequency
[32]
(F1 FREQUENCY)
[33]
Value:
[34]
0.0 - par. 426 F2 frequency
[35]
[36]
[37]
Function:
[38]
See parameter 423 U1 voltage .
[39]
[40]
par. 103
Par. 104 Motor frequency
