Logic or [3]
Bus Bus Dig.
Setup Setup Setup
msb lsb msb
0 0
0 0
0 0
0 0
0 1
0 1
0 1
0 1
1 0
1 0
1 0
1 0
1 1
1 1
1 1
1 1
513 Bus time interval
(BUS TIMEOUT TIME)
Value:
1 - 99 sec.
Function:
In this parameter it is possible to preset the maximum
time expected to elapse between receipt of two
consecutive telegrams. If this time is exceeded, the
serial communication is assumed to have stopped
and the desired reaction is preset in parameter
514 Bus time interval function.
Description of choice:
Preset the required time.
514 Bus time interval function
(BUS TIMEOUT FUNC)
Value:
Off (OFF)
Freeze output frequency (FREEZE OUTPUT)
Stop (STOP)
= factory setting. () = display text [] = value for use in communication via serial communication port
MG.28.H2.02 -
Dig. Setup
Setup no.
lsb
0 0 1
0 1 2
1 0 3
1 1 4
0 0 2
0 1 2
1 0 4
1 1 4
0 0 3
0 1 4
1 0 3
1 1 4
0 0 4
0 1 4
1 0 4
1 1 4
1 sec.
[0]
[1]
[2]
AKD 2800
Jogging (JOGGING)
Max. speed (MAX SPEED)
Stop and trip (STOP AND TRIP)
Function:
In this parameter you can select the required
reaction for the frequency converter when the
preset time in parameter 513 Bus time interval has
been exceeded. If choices [1] to [5] are activated
the output relay will be deactivated.
Description of choice:
The output frequency of the frequency converter
can be frozen at the present value, stop the motor,
be frozen at Jogging frequency (10 Hz), be frozen
at parameter 202 Output frequency, high limit
f or stop and activate a cut out.
MAX
[3]
[4]
[5]
