11. Technical data

11.1 Lifting station

Weight:
Temperature range:
Flood conditions:
Sound pressure level
11.1.1 Collecting tank
Material:
11.1.2 Pump
Motor:
Mains supply:
Insulation class:
Impeller type:
Enclosure class:
pH range:
Starts per hour:
Max. density of liquid:
Component Material
Pump housing Stainless steel
Impeller Stainless steel
Motor unit Parts in contact with
complete liquid: Stainless steel
Pump shaft - wet
Stainless steel
end
Motor cable Polychloroprene
O-rings NBR rubber
Oil Shell Ondina 15, non-toxic
Multilift MSS Duty
MSS.11.1.2
S3 -10 %, 1 min.
MSS.11.3.2

12. Disposal

This product or parts of it must be disposed of in an
environmentally sound way:
1. Use the public or private waste collection service.
2. If this is not possible, contact the nearest Grundfos company
or service workshop.
The crossed-out wheelie bin symbol on a product
means that it must be disposed of separately from
household waste. When a product marked with this
symbol reaches its end of life, take it to a collection
point designated by the local waste disposal
authorities. The separate collection and recycling of such
products will help protect the environment and human health.
16
Depending on variant.
See nameplate
0-40 °C
For short periods up to 60 °C
(max. 5 minutes per hour)
Max. 2 m for 7 days
< 70 dB(A) according to
EN 12050-1 and the Machinery
Directive
Polyethylene (PE)
1 x 230 V, 50 Hz
F (155 °C)
Vortex
IP68
4-10
max. 60
3
1100 kg/m
DIN
AISI
W.-Nr.
1.4301 304
1.4301 304
1.4401 316
1.4301 304
Voltage Power P1 / P2
[V] [kW]
1 x 230 V
1.8 / 1.1
3 x 400 V

11.2 LC 220 controller

Controller
Voltage variants, rated voltages: 1 x 230 V, 3 x 400 V
Voltage tolerances for LC 220:
Mains frequency for LC 220:
Supply system earthing:
Controller power consumption:
Backup fuse:
Control circuit fuse:
Ambient temperature:
During operation:
In stock:
Enclosure class:
Cabinet of LC 220
External dimensions:
Material:
Weight:
Outputs for alarm devices:
I / I RPM
1/1 start
-1
[A] [min ]
8 / 22.5
2760
3.2 / 16
- 15 %/+ 10 % of rated
voltage
50/60 Hz
For TN systems
7 W
Depending on variant.
See nameplate
Fine-wire fuse:
100 mA / 20 mm x ∅5
0 to +40 °C (must not be
exposed to direct sunlight)
-30 to +60 °C
IP55
Height = 195 mm
Width = 250 mm
Depth = 110 mm
ABS (acrylonitrile butadiene
styrene)
Depending on variant.
See nameplate
Max. 250 VAC / max.
2 A / min. 10 mA / AC1
Number of
Plug type
poles
E/F, I
-
2
CEE 3P+N+E, 16 A
