Bill Of Materials - Cypress CY8CKIT-059 PSoC 5LP Prototyping Kit Manual

A.3

Bill of Materials

Item Qty Reference
1 1 N/A N/A
C1, C3, C5,
C6, C10, C11,
C14, C18,
C20, C22,
2 19 C23, C27, 0.1 uF
C29, C32,
C33, C34,
C35, C39,
C40
3 1 C4 2200 pF
C7, C8, C9,
C12, C13,
C15, C16,
C21, C24,
4 17 1.0 uF
C25, C26,
C28, C30,
C31, C36,
C37, C38
5 1 C19 0.01 uF
6 2 C41, C42 22 pF
7 2 D1, D2 MBR0520L
PTC
8 2 F1, F2 Resettable
Fuse
9 1 J6 USB Micro-B
User LED
10 1 LED1
BLUE
POWER LED
11 1 LED2
Amber
Status LED
12 1 LED3
Green
13 2 R2, R3 15K
R4, R6, R16,
14 4 22E
R17
CY8CKIT-059 PSoC® 5LP Prototyping Kit Guide, Doc. #: 001-96498 Rev. *G
Value Description
PCB,
108.89mm × 24.13mm,
High Tg, ENIG finish, 2 layer,
Color = BLACK,
Silk = WHITE
CAP .1UF 16V CERAMIC
Y5V 0402
CAP CER 2200PF 50V 5%
NP0 0805
CAP CERAMIC 1.0UF 25V
X5R 0603 10%
CAP 10000PF 16V
CERAMIC 0402 SMD
CAP CER 22PF 50V 2%
C0G 0402
DIODE, SCHOTTKY, 20V,
0.5A, 400mW, SOD-123
FUSE, PTC Resettable,
0.50A, 16V, 1210, SMD
CONN RCPT STD MICRO
USB TYPE B
LED, BLUE, CLEAR, 0805,
SMD
LED 595NM AMB DIFF
0805 SMD
LED GREEN CLEAR 0805
SMD
RES SMD 15K OHM 5%
1/10W 0402
RES, 22 OHM, 1%,
100PPM, 1/16W, 0402
Mfr Name Mfr Part Number
Cypress
600-60178-01
Semiconductor
AVX Corporation 0402YG104ZAT2A
Murata Electronics GRM2165C1H222JA01D
Taiyo Yuden TMK107BJ105KA-T
TDK Corporation C1005X7R1C103K050BA
TDK Corporation C1005C0G1H220G050BA
Fairchild
MBR0520L
Semiconductor
Bel Fuse Inc 0ZCH0050FF2G
FCI 10103594-0001LF
Lite-On Inc LTST-C170TBKT
Avago Technologies
HSMA-C170
US Inc.
Chicago Miniature/
Visual
CMD17-21VGC/TR8
Communications
Company-VCC
Panasonic - ECG ERJ-2GEJ153X
Panasonic - ECG ERJ-2RKF22R0X
