Item Qty Reference
15 3 R5, R22, R23 ZERO
16 2 R7, R9 2.2K
17 1 R10 560 ohm
18 1 R12 100K
19 2 R13, R14 30K
R8, R11, R15,
20 4 ZERO
R20
21 2 R18, R21 820 ohm
22 2 SW1, SW3 Switch
23 1 TVS1 TVS DIODE
CY8C5868LTI
24 1 U1 -LP039
QFN68
CY8C5888LTI
25 1 U2 -LP097
QFN68
26 1 U3 NTZD3152P
No Load Components
1 2 C2, C17 0.1 uF
2 2 J1, J2 HDR 1x26
3 2 J3, J7 HDR 1x5
4 1 J4 HDR 1x2
50MIL
5 1 J5
KEYED SMD
6 2 J8, J9 HDR 1x7
7 2 R1, R19 4.7K
SW PUSH-
8 1 SW2
BUTTON
CY8CKIT-059 PSoC® 5LP Prototyping Kit Guide, Doc. #: 001-96498 Rev. *G
Value Description
RES SMD 0.0 OHM
JUMPER 06O3 1/10W
RES 2.2K OHM 1/10W 5%
0603 SMD
RES, 560 OHM, 5%,
200PPM, 1/10W, 0603, SMD
RES 100K OHM 1/10W 5%
0402 SMD
RES SMD 30K OHM 5%
1/10W 0402
RES SMD 0.0 OHM
JUMPER 1/8W 0805
RES, 820 OHM, 5%, 1/10W,
0603
SW, TACTILE SWITCH,
SPST-NO, 0.05A, 32V
DIODE, TVS, 5V, 350W,
SOD-323
PSoC 5LP CYC58LP, 67
MHz
PSoC 5LP CYC58LP, 80
MHz
FET DUAL P-CH 20V
430mA SOT-563
CAP .1UF 16V CERAMIC
Y5V 0402
CONN HDR BRKWAY
26POS VERT
2.54mm,15AU, TH
CONN HEADER 5POS .100
VERT TIN
CONN HEADR BRKWAY
.100 02POS STR
CONN, HEADER, MALE,
1.27mm, 10POS, GOLD,
SMD
CONN HEADER FEMALE
7POS .1" GOLD
RES SMD 4.7K OHM 5% 1/
10W 0402
SWITCH TACTILE SPST-
NO 0.05A 12V
Mfr Name Mfr Part Number
Panasonic - ECG ERJ-3GEY0R00V
Panasonic - ECG ERJ-3GEYJ222V
Panasonic - ECG ERJ-3GEYJ561V
Panasonic - ECG ERJ-2GEJ104X
Panasonic - ECG ERJ-2GEJ303X
Panasonic - ECG ERJ-6GEY0R00V
Panasonic - ECG ERJ-3GEYJ821V
C&K Components KMR221GLFS
Semtech SD05.TCT
Cypress
CY8C5868LTI-LP039
Semiconductor
Cypress
CY8C5888LTI-LP097
Semiconductor
ON Semiconductor NTZD3152PT1G
AVX Corporation 0402YG104ZAT2A
TE Connectivity 2-104427-4
Molex 22-23-2051
TE Connectivity 9-146280-0-02
Samtec Inc FTSH-105-01-L-DV-K
Sullins Connector
PPPC071LFBN-RC
Solutions
Panasonic - ECG ERJ-2GEJ472X
C&K Components PTS635SL50 LFS
