Section 14: TSP command reference
Trigger events
Event description
Trigger event blender N (1 to 2), which combines trigger
events
Notify trigger block N (1 to 8) generates a trigger event when
the trigger model executes it
Source limit condition occurs
Trigger timer N (1 to 4) expired
Line edge detected on TSP-Link synchronization line N
(1 to 3)
Example
print(trigger.tsplinkout[3].stimulus)
Also see
trigger.tsplinkout[N].assert()
tsplink.line[N].reset()

trigger.wait()

This function waits for a trigger event.
Type TSP-Link accessible
Function No
Usage
triggered = trigger.wait(timeout)
triggered
timeout
Details
This function waits up to timeout seconds for a trigger on the active command interface. A
command interface trigger occurs when:
•
A GPIB GET command is detected (GPIB only)
•
A VXI-11 device_trigger method is invoked (VXI-11 only)
•
A *TRG message is received
If one or more of these trigger events were previously detected, this function returns immediately.
After waiting for a trigger with this function, the event detector is automatically reset and rearmed.
This is true regardless of the number of events detected.
14-268
(on page 14-264)
(on page 14-272)
Affected by
A trigger was detected during the timeout period: true
No triggers were detected during the timeout period: false
Maximum amount of time in seconds to wait for the trigger
2470 High Voltage SourceMeter Instrument Reference Manual
Event constant
trigger.EVENT_BLENDERN
trigger.EVENT_NOTIFYN
trigger.EVENT_SOURCE_LIMIT
trigger.EVENT_TIMERN
trigger.EVENT_TSPLINKN
Outputs the event that will start action on
TSP-Link trigger line 3.
Where saved Default value
2470-901-01 Rev. A / May 2019
