2470 High Voltage SourceMeter Instrument Reference Manual

:TRIGger:LOAD "DurationLoop"

This command loads a predefined trigger model configuration that makes continuous measurements for a
specified amount of time.
Type
Command only
Usage
:TRIGger:LOAD "DurationLoop", <duration>
:TRIGger:LOAD "DurationLoop", <duration>, <delay>
:TRIGger:LOAD "DurationLoop", <duration>, <delay>, "<readingBuffer>"
<duration>
<delay>
<readingBuffer>
Details
When you load this predefined trigger model, you can specify amount of time to make a
measurement and the length of the delay before the measurement.
After selecting a trigger model template, you can view the trigger model blocks in a graphical format
by pressing the front-panel MENU key and under Trigger, selecting Configure. You can also add or
delete blocks and change trigger model settings from this screen. You can use the
TRIGger:BLOCk:LIST? command to view the trigger model blocks in a list format.
This command replaces the TRIGger:LOAD:LOOP:DURation command, which is deprecated.
Example
*RST
SOUR:FUNC VOLT
SOUR:VOLT 5
SENS:FUNC "CURR"
TRIG:LOAD "DurationLoop", 10, 0.01
INIT
Also see
:TRIGger:BLOCk:LIST?
2470-901-01 Rev. A / May 2019
Affected by
Not applicable
The amount of time for which to make measurements (167 ns to 100 ks)
The delay time before each measurement (167 ns to 10 ks); default is 0 for no delay
A string that indicates the reading buffer; the default buffers (defbuffer1 or
defbuffer2) or the name of a user-defined buffer; if no buffer is specified,
defbuffer1 is used
(on page 12-164)
Section 12: SCPI command reference
Where saved
Not applicable
Reset the instrument. Set the instrument to
source voltage at 5 V. Set to measure
current.
Load the Duration Loop trigger model to take
measurements for 10 s with a 10 ms delay
before each measurement.
Start the trigger model.
Default value
Not applicable
12-183
