2470 High Voltage SourceMeter Instrument Reference Manual

:TRIGger:BLOCk:BRANch:COUNter:RESet

This command creates a block in the trigger model that resets a branch counter to 0.
Type
Command only
Usage
:TRIGger:BLOCk:BRANch:COUNter:RESet <blockNumber>, <counter>
<blockNumber>
<counter>
Details
When the trigger model reaches the Counter Reset block, it resets the count of the specified Branch
on Counter block to zero.
Example
TRIG:LOAD "EMPTY"
TRIG:BLOC:BUFF:CLEAR 1
TRIG:BLOC:MEAS 2
TRIG:BLOC:BRAN:COUN 3, 5, 2
TRIG:BLOC:DEL:CONS 4, 1
TRIG:BLOC:BRAN:COUN 5, 3, 2
TRIG:BLOC:BRAN:COUN:RES 6, 3
Reset trigger model settings.
Clear defbuffer1 at the beginning of the trigger model.
Loop and make five readings.
Delay a second.
Loop three more times back to block 2.
Reset block 3 to 0.
Also see
:TRIGger:BLOCk:BRANch:COUNter
:TRIGger:BLOCk:BRANch:COUNter:COUNt?
2470-901-01 Rev. A / May 2019
Affected by
Recall settings
Instrument reset
Power cycle
The sequence of the block in the trigger model
The block number of the counter that is to be reset
(on page 12-147)
Where saved
Save settings
(on page 12-148)
Section 12: SCPI command reference
Default value
Not applicable
12-149
