Section 14: TSP command reference

trigger.tsplinkout[N].pulsewidth

This attribute sets the length of time that the trigger line is asserted for output triggers.
Type TSP-Link accessible
Attribute (RW) Yes
Usage
width = trigger.tsplinkout[N].pulsewidth
trigger.tsplinkout[N].pulsewidth = width
width
N
Details
Setting the pulse width to 0 asserts the trigger indefinitely.
Example
tsplink.line[3].mode = tsplink.MODE_TRIGGER_OPEN_DRAIN
trigger.tsplinkout[3].pulsewidth = 20e-6
Also see
trigger.tsplinkout[N].assert()

trigger.tsplinkout[N].release()

tsplink.line[N].mode
trigger.tsplinkout[N].release()
This function releases a latched trigger on the given TSP-Link trigger line.
Type TSP-Link accessible
Function Yes
Usage
trigger.tsplinkout[N].release()
N
Details
Releases a trigger that was asserted with an indefinite pulse width. It also releases a trigger that was
latched in response to receiving a synchronous mode trigger.
14-266
Affected by
Restore configuration
Instrument reset
Power cycle
TSP-Link line N reset
The pulse width (0.0 to 100 ks)
The trigger line (1 to 3)
(on page 14-264)
(on page 14-266)
(on page 14-271)
Affected by
The trigger line (1 to 3)
2470 High Voltage SourceMeter Instrument Reference Manual
Where saved
Configuration script
Sets pulse width for trigger line 3 to
20 μs.
Where saved
Default value
10e-6 (10 µs)
Default value
2470-901-01 Rev. A / May 2019
