System Settings

Set LNB Local Frequency
SETUP MODE ?
→ YES
Antenna Control Unit
1. Press LEFT arrow key to move cursor to YES and press OK key to enter
setup mode.
+ANTENNA
→+SYSTEM
Antenna Control Unit
2. Press DOWN arrow key to move cursor to SYSTEM and press OK key to enter
SYSTEM menu.
→+SET LOCAL
◀
+MODEM PORT
Antenna Control Unit
3. Press OK key to enter SET LOCAL menu to set the LNB local frequency.
→13V + 0KHz
◀
10000MHz
Antenna Control Unit
13V + 22KHz
10750MHz
Antenna Control Unit
4. Set the LNB Local Frequency for each corresponded voltage power .
(13V+0KHz, 18V+0KHz, 13V+22KHz, 18V+22KHz)
Press RETURN key and press LEFT and RIGHT arrow keys to select the parameter
you wish to edit. Press OK key to edit parameter. Or press RETURN key again to return
to the main display.
→ YES
Antenna Control Unit
5. Press LEFT arrow key to move cursor to YES and press OK key to save
current settings. Or move cursor to NO and press OK key to abort and return to
the main display.
NO
+SATELLITE
+INSTALLATION
+SET LOCATION
+BACKUP & RESTORE
18V + 0KHz
11300MHz
18V + 22KHz
▲ 09750MHz ▼
SAVE ?
NO
Operating the ACU
