2.3 Nameplate description - drive
identification
The drive label is found on the top surface of the control pod (right
angles to the display) on Unidrive sizes 1 to 3 and size 5 control module,
and on the side of the Unidrive size 4 and size 5 power module.
Figure 2-1 Typical drive rating labels
Unidrive size 1 to 4 rating label
Drive type
(STD,LV,
VTC, LFT)
Model
UNI3401 VTC
Drive
ratings
VOLTAGE 50/60 Hz 3Ph
CURRENT (A)
OVERLOAD: 40.8A FOR 60 SECS
SOFTWARE VERSION: 03.02.11
Unidrive size 5 control module rating label
UNIDRIVE SIZE 5
CONTROL MODULE HW2
IT IS ESSENTIAL TO READ
THE MANUAL BEFORE
CONNECTING THE DRIVE.
SOFTWARE VERSION: 03.02.11
3000005001
Unidrive size 5 power module rating label
Model
UNI5401 POWER MODULE HW2 110V FAN FITTED
Drive
VOLTAGE 50/60 Hz 3Ph
ratings
CURRENT (A)
Dual current
rating
2.4

Model variants

2.4.1 Unidrive standard industrial (STD)
...for constant torque loads (All frame sizes)
Operating modes:
Open Loop
Closed Loop vector
Servo
Regen
Overload:
Open loop 150% for 60s
Closed loop vector 175% for 60s (sizes 1 to 4), 150%* for 60s (size
5)
Servo 175% for 4s (sizes 1 to 4), 150%* for 4s (size 5)
Regen 150% for 60s
* Multiples of 300A output current with 120% overload or multiples of
240A with 150% overload
Unidrive User Guide
Issue Number: 9
Electrical Getting
Menu 0
Installation Started
Power rating
Customer and
date code
15kW
STDJ41
IT IS ESSENTIAL TO READ
THE MANUAL BEFORE
CONNECTING THE DRIVE.
INPUT OUTPUT
380/480V 380/480V
27A 34.0A
IND.
R
CONT..
EQ.
MADE IN THE U.K.
Model
Hardware
revision
TO BE USED IN CONJUNCTION
Customer and
WITH UNIDRIVE SIZE 5 HW2
POWER MODULES (S)
date code
STDL01
Approvals
IND.
CONT..
R
EQ.
MADE IN THE U.K.
IT IS ESSENTIAL TO READ
THE MANUAL BEFORE
CONNECTING THE DRIVE.
INPUT OUTPUT
380/480V 380/480V
220.0A 240.0A
OVERLOAD: 150 FOR 60 SECS
280.0A 300.0A
OVERLOAD: 120 FOR 60 SECS
www.controltechniques.com
Running
Optimisation Macros
the motor
Key to Approvals
R
Approvals
Customer and
date code
STDL01
Heatsink fan
HEATSINK FAN
ratings
110V/120V 50/60HZ
IND.
CONT..
EQ.
R Approvals
MADE IN
THE U.K.
Figure 2-2 Constant torque load
Advanced Technical
Diagnostics
Parameters Data
CE approval Europe
C Tick approval Australia
UL / cUL approval
Canada
Percent kW
and torque
100
Torque
80
60
kW
40
20
0
50 100
Percent speed
UL Listing
Information
USA &
