Figure 4-16 Unidrive VTC default terminal functions (European and USA)
EUR
Status relay
Drive normal
Analog frequency reference 1
Connections for
single-ended input
signal
Connections for
differential input signal
Analog frequency
reference 2
0 to 10V
FREQUENCY
TOTAL MOTOR
CURRENT
Motor thermistor
AT SPEED
RESET
PRESET SELECT
RUN FORWARD
RUN REVERSE
ANALOG INPUT /
PRESET REF SELECT
External trip
Unidrive User Guide
Issue Number: 9
Electrical Getting
Menu 0
Installation Started
Signal connector
1 11
21 31
1
2
5
6
3
0V common
0V common
4
7
0V common
11
9
10
8
0V common
21
22
23
0V common
24
25
Preset ref 1
26
Preset ref 2
27
28
Analog input
29
Preset ref
30
31
0V common
