Control Techniques Unidrive 1 Series User Manual page 154

Safety Product Mechanical
Information Information Installation
Parameter
9.01 Prog.-logic function 1 output indicator
9.02 Prog.-logic function 2 output indicator
9.03 Motorized pot. output indicator
Prog.-logic function 1 input 1 source
9.04
parameter
9.05 Prog.-logic function 1 input 1 invert
Prog.-logic function 1 input 2 source
9.06
parameter
9.07 Prog.-logic function 1 input 2 invert
9.08 Prog.-logic function 1 output invert
9.09 Prog.-logic function 1 delay
Prog.-logic function 1 destination
9.10
parameter
Prog.-logic function 2 input 1 source
9.14
parameter
9.15 Prog.-logic function 2 input 1 invert
9.16 Prog.-logic function 2 input 2 source
9.17 Prog.-logic function 2 input 2 invert
9.18 Prog.-logic function 2 output invert
9.19 Prog.-logic function 2 delay
Prog.-logic function 2 destination
9.20
parameter
9.21 Motorised pot. zero-start select
9.22 Motorised pot. bipolar select
9.23 Motorised pot. rate
9.24 Motorised pot. output scale factor
9.25 Motorised pot. destination
9.26 Motorised pot. up
9.27 Motorised pot. down
9.28 Motorised pot. reset
9.29 Binary-sum logic ones (MSB)
9.30 Binary-sum logic twos
9.31 Binary-sum logic fours
9.32 Binary-sum logic output value
9.33 Binary-sum logic destination parameter
RO Read Only parameter
RW Read / Write parameter
154
Electrical Getting
Menu 0
Installation Started
OL
Pr 0.00 to Pr 20.50
Pr 0.00 to Pr 20.50
Pr 0.00 to Pr 20.50
Pr 0.00 to Pr 20.50
Pr 0.00 to Pr 20.50
Pr 0.00 to Pr 20.50
Pr 0.00 to Pr 20.50
Pr 0.00 to Pr 20.50
Uni Unipolar variable parameter
Bi Bipolar variable parameter
Txt Text variable parameter
Bit Bit parameter
www.controltechniques.com
Running
Optimisation Macros
the motor
Range( )
CL
0 or 1
0 or 1
±100.0 %
0 or 1
0 or 1
0 or 1
0 to 25.0 s
0 or 1
0 or 1
0 or 1
0 to 25.0 s
0 or 1
0 or 1
0 to 250 s
0 to 4.000
0 or 1
0 or 1
0 or 1
0 or 1
0 or 1
0 or 1
0 to 7
R Reset required for new value to take effect
S New parameter-value saved at power-down
P Protected; forbidden as destination parameter
FLC Full-load current (max. continuous), Pr 11.32 { 0.33 }
Advanced Technical
Diagnostics
Parameters Data
Default( )
OL VT SV
Pr 0.00 RW Uni
0 RW Bit
Pr 0.00 RW Uni
0 RW Bit
0 RW Bit
0 RW Uni
Pr 0.00 RW Uni R
0 RW Uni
0 RW Bit
Pr 0.00 RW Uni
0 RW Bit
0 RW Bit
0 RW Uni
Pr 0.00 RW Uni R
0 RW Bit
0 RW Bit
20 RW Uni
1 RW Uni
Pr 0.00 RW Uni R
Pr 0.00 RW Uni R
Unidrive User Guide
Issue Number: 9
UL Listing
Information
Type
RO Bit P
RO Bit P
RO Bi S P
P
P
P
P
P
P
P
RO Bit
RO Bit
RO Bit
RO Bit
RO Bit
RO Bit
RO Uni P
P
