Menu 9: Programmable logic

Figure 10-14 Menu 9 logic diagram
Any bit
parameter
??.??
??.??
9.04
Any bit
parameter
??.??
??.??
9.06
Any bit
parameter
??.??
??.??
9.14
Any bit
parameter
??.??
??.??
9.16
Input
terminals
Output
terminals
The parameters are all shown at their default settings
152
Electrical Getting
Menu 0
Installation Started
Function-1
9.05
input-1 invert
x(-1)
Function-1 input-1
source parameter
Function-1
9.07
input-2 invert
x(-1)
Function-1 input-2
source parameter
Function-2
9.15
input-1 invert
x(-1)
Function-2 input-1
source parameter
Function-2
9.17
input-2 invert
x(-1)
Function-2 input-2
source parameter
Key
Read-write (RW)
0.XX
parameter
Read-only (RO)
0.XX
parameter
www.controltechniques.com
Running
Optimisation Macros
the motor
Function-1
output invert
9.08
9.09
x(-1)
Function-1
delay
Function-2
output invert
9.18
9.19
x(-1)
Function-2
delay
Advanced Technical
Diagnostics
Parameters Data
Function-1
Function-1
output
destination
indicator
parameter
9.01 9.10
Any
unprotected
bit
parameter
??.??
??.??
Function-2
Function-2
output
destination
indicator
parameter
9.02 9.20
Any
unprotected
bit
parameter
??.??
??.??
