Control Techniques Unidrive 1 Series User Manual page 30

Safety Product Mechanical
Information Information Installation
3.11.1 Unidrive size 1 filters
Figure 3-21 Unidrive size 1 bookcase mounted filter
Figure 3-22 Unidrive size 1 footprint or bookcase mounted filter
30
Electrical Getting
Menu 0
Installation Started
www.controltechniques.com
Running
Optimisation Macros
the motor
Advanced Technical
Diagnostics
Parameters Data
RFI Filter
4200-6105
Dimension
FS5111-10-29
UNI1201 to UNI1205
Model
UNI1401 to UNI1405
A 230mm (9.055in)
B 25mm (0.984in)
C 218mm (8.583in)
D 47.5mm (1.870in)
H 95mm (3.740in)
L 240mm (9.449in)
W 45mm (1.772in)
Z 4.5mm (0.177in)
Ground Terminal
RFI Filter
4200-6104
Dimension
FS5101-10-07
UNI1201 to UNI1205
Model
UNI1401 to UNI1405
A 380mm (14.961in)
B 35mm (1.378in)
C 60mm (2.362in)
F 364mm (14.331in)
G 16.5mm (0.650in)
H 68mm (2.677in)
L 390mm (15.354in)
300mm ±5mm
S
(11.811in ±0.197in)
U
3x 2.5mm
W 85mm (3.346in)
X M6 (4x)
Z 5.5mm (0.217in)
Ground
M5
Terminal
Unidrive User Guide
Issue Number: 9
UL Listing
Information
M5
2
(AWG14)
