Specifications

UVP Transilluminators
Single UV UVP Transilluminator models are designed with either single intensity or variable intensity.
Units are equipped with an electronic ballast.
Dimension: Width: 14" x Depth: 11" x Height: 4.8" (356 x 279 x 122mm)
Model Part Number
M-15 95-0455-01
95-0455-02
M-15V 95-0456-01
95-0456-02
M-20 95-0447-01
95-0447-02
M-20V 95-0452-01
95-0452-02
M-26 95-0457-01
95-0457-02
M-26V 95-0458-01
95-0458-02
M-26XV 95-0413-01
95-0413-02
The mini single UV UVP Transilluminator uses a magnetic core/coil design ballast. The transilluminator
dimensions are: 7.25"D x 10.25"W x 4.5"H. This model has a single intensity.
Model Part Number
M-10E 95-0180-01
95-0180-02
95-0180-03
UVP 2UV Transilluminators
Units are equipped with an electronic ballast. This model has a single intensity. The physical dimensions
of all models are:
Width: 14" x Depth: 11" x Height: 4.8" (356 x 279 x 122mm)
Model Part Number
LM-20 95-0449-01
95-0449-02
LM-26 95-0459-01
95-0459-02
Volt/Hz Wavelength
100-115/60 302nm
230/50
100-115/60 302nm
230/50
100-115/60 302nm
230/50
100-115/60 302nm
230/50
100-115/60 302nm
230/50
100-115/60 302nm
230/50
100-115/60 302nm
230/50
Volt/Hz/Amp Wavelength
115/60/0.7 302nm 10 x 10cm
230/50/0.6
100/50-60/0.8
Volt/Hz Wavelength
100-115/60 302/365nm
230/50
100-115/60 302/365nm
230/50
No. of Intensity
Filter Size Tubes Style
15 x 15cm 4 x 8W Single
15 x 15cm 4 x 8W Variable
20 x 20cm 4 x 8W Single
20 x 20cm 4 x 8W Variable
21 x 26cm 4 x 8W Single
21 x 26cm 4 x 8W Variable
25 x 26cm 4 x 8W Variable
Filter Size No. of Tubes
5 x 6W
Filter Size #of Tubes/UV
20 x 20cm 4 x 8W/302nm
4 x 8W/365nm
21 x 26cm 4 x 8W/302nm
4 x 8W/365nm
