UVP Transilluminators
Maintenance/Repair/Technical Assistance

Replacement Parts/Accessories

For replacement parts or components not shown here, contact Analytik Jena Customer Service or place
of purchase. Please have the transilluminator model number available when you call.
Replacement Part Description
UVP Filter Assembly (M-10)
Filter Assembly (M-15)
Filter Assembly (M-15V)
UVP Filter Assembly (M-20)
UVP Filter Assembly (M-26)
Filter Assembly (M-20V, LM-20, LMS-20)
Filter Assembly (M-26V, LM-26, LMS-26)
Filter Assembly (M-26XV)
UVP Cover, UV blocking (M-10E)
UVP Cover, UV blocking (all other models)
UV Tube, 6 Watt, 302nm midrange (FL6E) – TM-10E
UV Tube, 8 Watt, 302nm midrange (FL8E)
Tube, 8 Watt, 365nm longwave UV (F8T5/BL)
Tube, 8 Watt, 254nm shortwave UV
Accessories Description
UVP Gel-Cutter
UVP Gel-Scooper
UVP Gel-Tray, UV Transmitting, Sm. 11.5"W x 9"D (29 x 23cm)
UVP Gel-Tray, UV Transmitting, Lg. 16.5"W x 10.5"D (42 x 27cm)
UVP Gel-Tray, UV Transmitting (25 x 26cm)
UVP Gel-Ruler, UV Fluorescing
UVP Spectacles, UV Blocking
UVP Goggles, UV Blocking
UVP Faceshield, UV Blocking
Part Number Qty. Required
38-0150-01 1
38-0313-03 1
38-0313-09 1
38-0313-01 1
38-0313-02 1
38-0313-07 1
38-0313-08 1
38-0163-04 1
19-0114-01 1
19-0121-01 1
34-0044-01 5
34-0042-01 4
34-0006-01 4
34-0007-01 4
Part Number
85-0002-01
85-0006-01
85-0007-01
85-0005-01
38-0296-03
85-0003-01
98-0002-01
98-0002-02
98-0002-04
81-0249-01 Rev H
