Comestero Suzohapp Multi PRO Operating Manual page 88

10.4.4.1 System Info
Touching the "System info" button reproduced on the right
in the screen shown in Figure 108 will display the screen
(shown in Figure 110 below) allowing to display the serial
number, the IP address and the firmware version of the
machine; it also allows to set a name and a code by touching
the relevant buttons.
10.4.4.2 Export
Touching the "Export" button reproduced on the right in the
screen shown in Figure 108 will display the relevant menu
home page.
This screen (shown in Figure 111 below) allows to access the data export functions provided
by the system. Make sure you plugged a FAT32-formatted pen drive into the special USB
connector inside the machine.
Figure 110
Figure 111
