Comestero Suzohapp Multi PRO Operating Manual page 71

Multi PRO – Operating Manual
10.4.1.10 POS (function only available if a POS is installed)
This page allows to set a minimum threshold below which the purchase by POS will not be
allowed.
71
The "Test" buttons allow to simulate the activation of a program and
indicate the corresponding output(s) (in binary mode) in the terminal
strip connection diagram, making testing the wiring easier than ever.
The eighth output of the MaxiBio terminal strip allows to drive a coin
vacuum system. It is activated for 2 seconds every time any coins are
collected.
Figure 79
Figure 80
