6.2.2 Hopper - free-standing version

In the free-standing cabinet version, hoppers are located as shown in Figure 13 above. You
have the option to install no hopper (A), a single hopper (B), two hoppers (C) or three hoppers
(D).
6.2.3 Payment systems – free-standing and recessed version
The following picture shows all the payment systems available with Multi PRO in its free-
standing and recessed versions. In these two configurations, the available payment systems
you can install are the same. As a consequence, there are multiple combinations of payment
systems available. The figure below shows the types of devices that can be installed and the
possible location of the inputs for banknotes, coins and cashless systems.
Figure 14
Figure 13
RM5 HD coin validator
EuroKey Next
cashless system
Nv9 USB banknote reader
