As mentioned above, to connect the machine to the MaxiBio board, the user must use the
Standard RS485 cable already connected to the machine CPU
Even the MaxiBio board is not included in the packaging and must be requested from
COMESTERO to ensure that the connected system is properly driven. To connect the MaxiBio
board to the gantry car wash, use cables that can withstand a 230 Vac voltage. These cables
must be supplied by the installer.
N.B.
For proper connection, a double insulation is required between the 230 Vac and the low
voltage cables, if they are not separated.
N.B.
The MaxiBio board must be installed inside a technical compartment, to be solely accessed
by qualified personnel. Do not install the boards inside the machines. Install the MaxiBio
boards inside special junction boxes having at least an IP55 protection rating.
Using cables equipped with "GROUND" wire, connect the GROUND wire to the "GROUND" of
the unit.
To avoid any "Antenna" effect, connect any unused wires to the
"GROUND" of the equipment.

7.3 Connection to the Ethernet network

To exploit Multi PRO to its fullest potential, it is advisable that you connect the machine to the
Ethernet network via a dedicated cable. Connect an Ethernet network cable, with a rating at
least equal to category 5, to the Ethernet port of your PC and to a free Ethernet port on the
hub. The Ethernet hub is located on the right-hand inner wall of the machine.
Cn6 Program3
Cn8 Program4
Cn10 Program5
Cn12 Program6
Cn14 Program7
Cn16 Coin and banknote extractor
