Multi PRO – Operating Manual
N.B.
The operation and the on-board configuration procedures remain the same for both Multi
PRO versions.

6.2 Device options

Multi PRO offers several configuration options depending on the different customer needs.

6.2.1 Hopper - recessed version

In the recessed cabinet version, hoppers are located as shown in Figure 12 above. You have
the option to install no hopper (A), a single hopper (B), two hoppers (C) or three hoppers (D).
27
Design variants differ internally by the combination and location of the
devices installed on them, and externally by the location of the payment
devices.
Figure 12
