Appendix 2
Beam diameter
The following figures show the beam diameter of each sensor head type.
■10mm type
MH11H01A0SNA
Small spot
MH11H01A0LNA
Line spot
(Unit: mm)
■30mm type
0.22
MH11H03B0SNA
Small spot
Measurement center distance
MH11H03B0LNA
Line spot
(Unit: mm)
■50mm type
0.13
MH11H05†0SNA
Small spot
Measurement center distance
MH11H05†0LNA
Line spot
(Unit: mm)
Characteristics
ø0.12
ø0.02
Measurement range
Measurement center distance
0.55
0.70
0.12
0.03
0.18
Measurement range
0.85
1.2
0.18
0.07
0.11
Measurement range
0.7
1.0
0.11
ø0.12
0.85
0.02
0.22
0.03
0.18
1.55
0.03
0.18
0.13
0.07
0.11
1.3
0.07
0.11
0.12
APPX

Appendix 2 Characteristics
