■85mm type (MH11H08B0SNA, MH11H08B0LNA, MH11H08C0SNA, MH11H08C0LNA)
• Diffuse reflection installation
26
(Measurement center distance)
13
Light
reception axis
(Unit: mm)
• Specular reflection installation
(Measurement center distance)
81.4
Light emission axis
14°
Light reception axis
Specular reflection line
The reference surface for specular reflection installation
(Unit: mm)
APPX
60
Appendix 1 External Dimensions
85
Light emission axis
28°
5
86.3
23.1
44
9
2-M5 mounting hole
Depth:10
(same as the hole at the
diagonal position)
74
Laser emission indicator
(green)
Measurement range
indicator (yellow)
64
ø6.6
(3.5)
6.2
(ø14.7)
