Press V/v repeatedly to select
the item you want, then press
• Retry: Performs the Auto Calibration
• Save: Save the measurement results and
exits the setting process.
• Warning: Displays warning related to
the measurement results. See "Message
list after Auto Calibration
measurement" (page 38).
• Exit: Exits the setting process without
saving the measurement results.
Save the measurement result.
Select "Save" in step 7.
You can select the calibration type you want by
using the "Custom" Auto Calibration
Disconnect the optimizer
microphone from the receiver.
If you reposition your speaker, we recommend that
you perform Auto Calibration again to enjoy the
• You can change the unit of distance in "Distance
Unit" in the Speaker settings menu (page 66).
• The size of a speaker ("Large"/"Small") is
determined by the low frequency characteristics.
The measurement results may vary, depending on
the position of the optimizer microphone and
speakers, and the shape of the room. It is
recommended that you apply the measurement
results. However, you can change those settings in
the Speaker Settings menu. Save the measurement
results first, then try to change the settings.
To cancel Auto Calibration
The Auto Calibration function will be
canceled when you perform the following
during the measurement process:
– Press ?/1.
– Press the input buttons on the remote control
or turn the INPUT SELECTOR on the
– Press MUTING or
– Press SPEAKERS on the receiver.
– Change the volume level.
– Connect the headphones.
– Press SHIFT, then press AUTO CAL again.
Checking the Auto Calibration
To check error code or warning message
obtained in "Performing Auto Calibration"
(page 36), proceed with the following steps.
Press V/v to select "Warning" in
step 7 in "Performing Auto
Calibration" (page 36) then press
If a warning message appears, check the
message and use the receiver without change.
Or if necessary, perform Auto Calibration
When "Error Code" appears
Check the error and perform Auto Calibration
to select "ENTER".
"RETRY ?" appears on the TV screen.
Press B/b to select "YES", then press
Repeat step 6 to 9 in "Performing Auto
Calibration" (page 36).
