Factory Reset
Reset the controller to factory settings.
Go Homepage (s)
Set the time of staying on the current screen before going back to the homepage
when no action is performed. The time range is 30s to 3600s.
OLED Brightness
Adjust the brightness of the OLED menu screen on the front panel.
Hardware Version
Check the hardware version of the controller. If a new version is released, you can
update the firmware programs in NovaLCT or SmartLCT.

Communication Settings

Set the communication mode and network parameters of the MCTRL660 PRO.




Working Mode

The MCTRL660 PEO allows you to switch between sending card mode and fiber
converter mode.
www.novastar.tech
Communication mode: USB preferred and Local Area Network (LAN) preferred
The controller connects to PC via the USB port or ETHERNET port. If USB
Preferred is selected, the PC prefers to communicate with the controller via the
USB port, or else via the ETHERNET port.
Network settings can be manual or automatic.
Manual settings parameters include controller IP address and subnet mask.
−
− Automatic settings can read the network parameters automatically.
Reset: Reset the network parameters to default values.
