MCTRL660 PRO Independent Controller
User Manual
Appearance
5.1.1 Front Panel
No.
1
2
3
4
5
6
7
5.1.2 Rear Panel
Connector Name
Connector
www.novastar.tech
5
Description
Operating indicator
Green: The device is running normally.
Red: The device is in standby mode.
Standby button
OLED operation screen
Function knob
BACK button: Press to go back to the previous menu.
INPUT button: Press to choose a video source.
USB port: Used to update firmware
Description
Hardware Structure
5 Hardware Structure
7
