MCTRL660 PRO Independent Controller
User Manual
Type
DVI IN
Input
HDMI IN
3G-SDI IN
Output RJ45 × 6
www.novastar.tech
Single-link DVI connector

 Custom resolutions supported:
Maximum width: 3840 pixels
Maximum height: 2560 pixels
Supported standard resolutions:

1024×768@(24/30/48/50/60/72/75/85/100/120)Hz
1280×1024@(24/30/48/50/60/72/75/85)Hz
1366×768@(24/30/48/50/60/72/75/85/100)Hz
1440×900@(24/30/48/50/60/72/75/85)Hz
1600×1200@(24/30/48/50/60)Hz
1920×1080@(24/30/48/50/60)Hz
1920×1200@(24/30/48/50/60)Hz
2560×960@(24/30/48/50)Hz
2560×1600@(24/30)Hz
HDMI 1.4a compliant

 HDCP 1.4 compliant
 Custom resolutions supported:
Maximum width: 3840 pixels
Maximum height: 2560 pixels
Supported standard resolutions:

1024×768@(24/30/48/50/60/72/75/85/100/120)Hz
1280×1024@(24/30/48/50/60/72/75/85)Hz
1366×768@(24/30/48/50/60/72/75/85/100)Hz
1440×900@(24/30/48/50/60/72/75/85)Hz
1600×1200@(24/30/48/50/60)Hz
1920×1080@(24/30/48/50/60)Hz
1920×1200@(24/30/48/50/60)Hz
2560×960@(24/30/48/50)Hz
2560×1600@(24/30)Hz
 SMPTE ST 425-1 Level A & B, SMPTE ST 274, ST 296, ST 295
compliant
 Maximum supported input resolution: 1920×1080@60Hz
Note: 3G-SDI input sources do not support input resolution settings.
6 Gigabit Ethernet ports

 Maximum loading capacity of a single Ethernet port:
For 8-bit input sources: 650,000 pixels
−
For 10-bit/12-bit input sources: 320,000 pixels
−
 Support redundancy between Ethernet ports.
