Installation
3.2
DIN Rail Mounting
Mount on DIN rail
1.
Hook the unit onto the upper lip of
the rail and push gently downwards.
2.
Push the unit towards the rail until it
snaps into place.
Remove from DIN rail
1.
Push the unit gently downwards on the rail.
2.
Pull the bottom end of the unit free of the rail and remove it.
3.3
Power Connector
See also
Technical Data, p. 59
Pin
1
2
3.4
USB Connector
The USB connector is only used when upgrading the firmware of the unit. It cannot be used for
configuration purposes.
Pin
1
2
3
4
Housing
Anybus
®
X-gateway
™
CANopen
®
PROFINET
The unit must be electrically grounded through the DIN rail for EMC compliance.
regarding power supply requirements.
Signal
+24 VDC
Power Ground
Signal
+5 V input
USBDM (USB communication)
USBDP (USB communication)
Signal ground
Cable shield
®
IRT (2.32) User Manual
Fig. 4
Push down to mount or remove
Fig. 5
Power connector
Fig. 6
USB type B connector
9 (60)
1
2
2
1
3
4
SCM-1202-029 1.2 en-US
