Installation
3.6

PROFINET IRT Network Interface

Fig. 10 PROFINET IRT interface
Ethernet Connectors (LAN 1/LAN 2)
The PROFINET IRT interface contains a dual port Ethernet switch with RJ45 type connectors. The
two ports are labeled LAN 1 and LAN 2.
Pin
1
2
3
6
4, 5, 7, 8
Anybus ® X-gateway ™ CANopen ® PROFINET
LAN 1
Function
TD+
TD-
RD+
RD-
(reserved)
® IRT (2.32) User Manual
LAN 2
Fig. 11 Ethernet connector (RJ45)
11 (60)
1 8
