Installation
2.2
DIN Rail Mounting
Mount on DIN rail
Fig. 1
1.
Hook the unit onto the upper lip of the rail and push gently downwards.
2.
Push the unit towards the rail until it snaps into place.
Remove from DIN rail
1.
Push the unit gently downwards on the rail.
2.
Pull the bottom end of the unit free of the rail and remove it.
Anybus
®
Communicator
The unit must be electrically grounded through the DIN rail for EMC
compliance.
Push down to mount or remove
™
Startup Guide
5 (12)
SP2444 1.0 en-US
