3. Programming
The small digits to the left are the selected
3
The large digits in the middle of the display show the
lected parameter.
The right side of the display shows the
This can be either Hz, A, V, kW, HP, %, s or RPM.
Motor direction is shown to the bottom left of the display - indicated
by a small arrow pointing either clockwise or counterclockwise.
Use the [MENU] key to select one of the following menus:
Status Menu:
The Status Menu is either in
display.
Hand on Mode
In the local LCP reference is displayed.
Quick Menu:
Displays Quick Menu parameters and their settings. Parameters in the Quick Menu can be accessed and edited from here. Most applications can be run
by setting the parameters in the Quick Menus.
Main Menu:
Displays Main Menu parameters and their settings. All parameters can be accessed and edited here. A parameter overview is found later in this manual.
Indicator lights:
• Green LED: The frequency converter is on.
• Yellow LED: Indicates a warning. Please see section
• Flashing red LED: Indicates an alarm. Please see section
8
parameter number.
value of the se-
unit of the selected parameter.
Readout Mode or Hand on Mode . In Readout Mode
Troubleshooting
Troubleshooting
MG.02.C4.02 - VLT is a registered Danfoss trademark
Illustration 3.4: Indicating selected par. no.
Illustration 3.5: Indicating value of selected par.
Illustration 3.6: Indicating unit of selected par.
Illustration 3.7: Indicating motor direction
the value of the currently selected readout parameter is shown in the
