VLT Micro Drive FC 51
[5] Not and
[6] Not or
[7] Not and not
[8] Not or not
13-44 Logic Rule Boolean 3
Array [4]
4.10.6. 13-5* States
Parameters for programming the Smart Logic Controller.
13-51 SL Controller Event
Array [20]
13-52 SL Controller Action
Array [20]
* Disabled
[0]
[1] No Action
[2] Select Set-up1
[3] Select Set-up2
[10] SelectPresetRef0
[11] SelectPresetRef1
[12] SelectPresetRef2
[13] SelectPresetRef3
[14] SelectPresetRef4
[15] SelectPresetRef5
[16] SelectPresetRef6
[17] SelectPresetRef7
[18] SelectRamp1
[19] SelectRamp2
[22] Run
[23] RunReverse
[24] Stop
[25] Qstop
[26] DCstop
[27] Coast
[28] Freeze Output
[29] StartTimer0
[30] StartTimer1
[31] StartTimer2
[32] SetDO42Low
[33] SetRelayLow
[38] SetDO42High
Evaluates expression NOT [13-40/13-42] and [13-44].
Evaluates expression NOT [13-40/13-42] OR [13-44].
Evaluates expression NOT [13-40/13-42] AND NOT [13-44].
Evaluates expression NOT [13-40/13-42] OR NOT [13-44].
Select third boolean input for selected logic rule.
See par. 13-40 for choices and descriptions.
Select boolean input to define Smart Controller Event.
See par. 13-40 for choices and descriptions.
Select action corresponding to SLC event. Actions are executed when corresponding event (par. 13-51) is eval-
uated as True .
Function is disabled.
No action is taken.
Changes active set-up to Set-up 1.
Changes active set-up to Set-up 2.
Selects preset reference 0
Selects preset reference 1
Selects preset reference 2
Selects preset reference 3
Selects preset reference 4
Selects preset reference 5
Selects preset reference 6
Selects preset reference 7
Selects ramp 1
Selects ramp 2
Issues start command to frequency converter.
Issues start reverse command to frequency converter.
Issues stop command to frequency converter.
Issues quick stop command to frequency converter.
Issues DC stop command to frequency converter.
Frequency converter coasts immediately. All stop commands including coast command stop the SLC.
Freezes output frequency.
Starts timer 0.
Starts timer 1
Starts timer 2
Set Digital output 42 low.
Set Relay low.
Set Digital output 42 high.
