4. Parameter Descriptions
[23] Setup select bit 0
[26] Precise stop inverse
(only terminal 33)
[27] Start, precise stop (on-
ly terminal 33)
[28] Catch up
[29] Slow down
[32] Pulse input (only termi-
4
nal 33)
[34] Ramp bit 0
[60] Counter A (up)
[61] Counter A (down)
[62] Reset counter A
[63] Counter B (up)
[64] Counter B (down)
[65] Reset counter B
5-10 Terminal 18 Digital Input
Option:
* Start
[8]
5-11 Terminal 19 Digital Input
Option:
Reversing
*
[10]
5-12 Terminal 27 Digital Input
Option:
Reset
*
[1]
5-13 Terminal 29 Digital Input
Option:
Jog
*
[14]
5-15 Terminal 33 Digital Input
Option:
Preset bit 0
*
[16]
4.6.3. 5-4* Relays
Parameter group for configuring timing and output functions for relays.
[0] No Operation
[1] Control Ready
[2] Drive Ready
[3] Drive Ready, Remote
34
Set par. 0-10 Active set-up to Multi set-up.
Logic 0 = set-up 1, Logic 1 = Set-up 2.
Prolong the stop signal to give a precise stop independent of scan time. The function is available for terminal
33 only.
As [26], but including Start.
Select Catch up/Slow down to increase or reduce the resulting reference value by the percentage set in par.
3-12.
Same as Catch up [28]
Select Pulse input when using a pulse sequence as either reference or feedback. Scaling is done in par. group
5-5*.
Logic 0 = Ramp1, see par. 3-4*.
Logic 1 = Ramp2, see par. 3-5*.
Input for counter A.
Input for counter A.
Input for reset of counter A.
Input for counter B.
Input for counter B.
Input for reset of counter B.
Function:
Select function from available digital input range.
See par. 5-1* for choices.
Function:
Select function from available digital input range.
See par. 5-1* for choices.
Function:
Select function from available digital input range.
See par. 5-1* for choices.
Function:
Select function from available digital input range.
See par. 5-1* for choices.
Function:
Select function from available digital input range.
See par. 5-1* for choices.
Default for all digital and relay outputs.
Control board receives supply voltage.
Frequency converter is ready for operation and applies supply signal on control board.
Frequency converter is ready for operation in Auto On-mode.
