VLT Micro Drive FC 51
[1] On
13-01 Start Event
Option:
[0] False
[1] True
[2] Running
[3] InRange
[4] OnReference
[7] Out of Current Range
[8] BelowILow
[9] AboveIHigh
[16] ThermalWarning
[17] MainsOutOfRange
[18] Reversing
[19] Warning
[20] Alarm_Trip
[21] Alarm_TripLock
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] LogicRule 0
[27] LogicRule 1
[28] LogicRule 2
[29] LogicRule 3
[33] DigitalInput_18
[34] DigitalInput_19
[35] DigitalInput_27
[36] DigitalInput_29
[38] DigitalInput_33
StartCommand
*
[39]
[40] DriveStopped
13-02 Stop Event
Option:
[0] False
[1] True
[2] Running
[3] InRange
[4] OnReference
[7] Out of Current Range
[8] BelowILow
[9] AboveIHigh
[16] ThermalWarning
[17] MainsOutOfRange
SLC is active.
Function:
Select input to activate Smart Logic Control.
Enters False in logic rule.
True
Enters in logic rule.
See par. 5-4* [5] for description.
See par. 5-4* [7] for description.
See par. 5-4* [8] for description.
See par. 5-4* [12] for description.
See par. 5-4* [13] for description.
See par. 5-4* [14] for description.
See par. 5-4* [21] for description.
Mains voltage is outside the specified voltage range.
See par. 5-4* [25] for description.
A warning is active.
A trip alarm is active.
A trip lock alarm is active.
Use result of comparator 0 in logic rule.
Use result of comparator 1 in logic rule.
Use result of comparator 2 in logic rule.
Use result of comparator 3 in logic rule.
Use result of logic rule 0 in logic rule.
Use result of logic rule 1 in logic rule.
Use result of logic rule 2 in logic rule.
Use result of logic rule 3 in logic rule.
Use value of DI 18 in logic rule.
Use value of DI 19 in logic rule.
Use value of DI 27 in logic rule.
Use value of DI 29 in logic rule.
This event is True , if frequency converter is started by any means (digital input or other).
This event is True , if frequency converter is stopped or coasted by any means (digital input or other).
Function:
Select input to activate Smart Logic Control.
Enters False in logic rule.
Enters True in logic rule.
See par. 5-4* [5] for description.
See par. 5-4* [7] for description.
See par. 5-4* [8] for description.
See par. 5-4* [12] for description.
See par. 5-4* [13] for description.
See par. 5-4* [14] for description.
See par. 5-4* [21] for description.
Mains voltage is outside the specified voltage range.
MG.02.C4.02 - VLT is a registered Danfoss trademark
4. Parameter Descriptions
49
4
