4. Parameter Descriptions
NB!
Factory Set-up
0-10 Active Set-up
Option:
4
Set-up 1
*
[1 ]
[2] Set-up 2
[9] Multi Set-up
0-11 Edit Set-up
Option:
Set-up 1
*
[1 ]
[2] Set-up 2
[9] Active Set-up
0-12 Link Set-ups
Option:
[0] Not linked
* Linked
[1 ]
4.1.2. 0-31 Custom Readout Min Scale
0-31 Custom Readout Min Scale
Range:
*
0.00 [0.00 – 9999.00 ]
12
cannot be used as Active Set-up .
Function:
Active Set-up controls the motor.
Shifts between set-ups can only happen when
• the motor is coasted
OR
• the set-ups between which the shift happens are linked to each other (see par. 0-12,
ups
).
If changing between set-ups that are not linked, the change will not happen before motor is coasted.
NB!
The motor is only considered stopped when it is coasted.
Set-up 1 is active.
Set-up 2 is active.
Select the active set-up via digital input and/or bus, see par. 5-1* choice [23].
Function:
The Edit Set-up is for updating parameters in the frequency converter from either LCP or bus. It can be identical
Active Set-up
or different from the
All set-ups can be edited during operation, independently of the active set-up.
Update parameters in Set-up 1 .
Update parameters in Set-up 2 .
Update parameters in set-up selected as
Function:
The link ensures synchronizing of the "not changeable during operation" parameter values enabling shift from
one set-up to another during operation.
If the set-ups are not linked, a change between them is not possible while the motor is running. Thus the set-
up change does not occur until the motor is coasted.
Leaves parameters unchanged in both set-ups and cannot be changed while motor runs.
Copy parameters "not changeable during operation" parameter values into presently selected
NB!
This parameter cannot be changed while motor runs.
Function:
It is possible to create a customized readout related to the output frequency of the unit. The value entered in
par. 0-31 will be shown at 0 Hz. The readout can be shown in the LCP display when in Status Mode or it can be
read in par. 16-09
MG.02.C4.02 - VLT is a registered Danfoss trademark
.
Active Set-up
(see par. 0-10).
